1037 Container Load-Unload
Key Advantages
The ideal solution when you need extended reach beyond a single-stage conveyor.
Designed with a compact footprint, this newest addition to our telescopic conveyor family is perfect for efficiently unloading pup trailers, short track trailers, or containers 30 ft. or less. Equipped with intuitive and precise controls, this four-stage telescopic conveyor streamlines loading and unloading operations. It extends up to 27 ft. from the base to the boom’s end, ensuring optimal reach. The hydraulic front cylinders enable easy height adjustments, allowing operators to raise or lower the conveyor for more ergonomic and efficient trailer or container handling.
CONNECT WITH OUR EXPERTS
Specifications
| Overall Length | 37 ft. |
| Boom Extension Length | 27 ft. |
| Retracted Length | 10 ft. (2 in. overhang with bumper) |
| Machine Base Width | 3 ft. 9 in. |
| Discharge Elevation | 5 ft. to 5 ft. 9 in. field welded |
| Capacity | 50 lbs./linear ft. |
| Power Supply | 480 V, 3-phase, 24 VDC controls |
| Hydraulic Power Supply | 3 HP, 480 V, dual-speed lowering/variable speed raise |
| Stand | Dock-high or platform-high |
| Electrical Control Panel | U.L. Panel w/ Schneider PLC with open I/O's Altivar VFD's for belt drive and boom extension. Rotary Disconnect, Mushroom E-Stop. |
| Enclosure | Mount Right/left hand, remote |
| Boom Controls | 4-way up/down/in/out, belt on/off |
| Boom Extension Drive | 3/4 HP Sumitomo, VFD Controlled |
| Belt Drive | 3 HP Van der Graaf Motorized Pulley, VFD Controlled |
| Belt Width | 21 in. |
| Belt Direction | Unload only or Load/Unload |
| Belt Speed | Multiple speeds up to 100 ft./min |
Additional Options
| Option 1 | Skirting |
| Option 2 | Package Frame Assembly |
| Option 3 | Handrail Assembly |
| Option 4 | Maintenance Cord Pendant |
| Option 5 | Spare Fuse Kit |
| Option 6 | Spacer Kit (Convert Dock-High to Platform Application) |
| Option 7 | Dock-High or Platform Configuration |
